MAN B&W 18.04
Page 6 of 7
MAN Diesel
MAN B&W ME/MEC/ME-B/GI engines 198 45 838.10
Slow down for UMS – Class and MAN Diesel & Turbo requirements
Table 18.04.03: Slow down functions for UMS
ABS
BV
CCS
DNV
GL
KR
LR
NK
RINA
RS
IACS
MAN Diesel
Sensor and
function Point of location
111111111111TE 8106 YH Thrust bearing segment
1111*11111111PT 8108 YL Lubricating oil inlet to main engine
1 1 TE 8112 YH Lubricating oil inlet to main engine
111111 11111TE 8113 YH Piston cooling oil outlet/cylinder
111111 11111FS 8114 YL Piston cooling oil outlet/cylinder
1 TE 8123 YH Main bearing oil outlet temperature/main bearing
(S40/35ME-B9 only)
1 XC 8126 YH Bearing wear (All except S40/35ME-B9)
1111 1111111PT 8401 YL Jacket cooling water inlet
1 PDT 8403 YL Jacket cooling water across engine (Not for LDCL)
1 PDT 8404
YL
Jacket cooling water across cylinder liners (Only for
LDCL)
1 PDT 8405
YL
Jacket cooling water across cylinder covers and ex-
haust valves (Only for LDCL)
111111111111TE 8408 YH Jacket cooling water outlet, cylinder/cylinder
1 1 1 TE 8609 YH Scavenge air receiver
111111111111TE 8610 YH Scavenge air box fire-alarm, cylinder/cylinder
1 1 1 TC 8701 YH Exhaust gas before turbocharger/turbocharger
11 111111111TC 8702 YH Exhaust gas after exhaust valve, cylinder/cylinder
1 1 TC 8702 YH Exhaust gas after exhaust valve, cylinder/cylinder,
deviation from average
1 WT 8812 YH Axial vibration monitor 2)
11 1* 1111111XS 8813 YH Oil mist in crankcase/cylinder
1 XS/XT
8817 Y
Turbocharger overspeed (Only in case of VT TC, Waste
Heat Recovery, Exhaust Gas Bypass, TC Cut-out)
1 1 TE 1310 YH Lubrication oil inlet (Only for ME/-GI with separate oil
system to HPS installed)
1 Indicates that the sensor is required.
The sensors in the MAN Diesel and relevant Class columns are included in the basic Extent of Delivery, EoD: 4 75 127.
The sensor identification codes and functions are listed in Table 18.07.01.
The tables are liable to change without notice, and are subject to latest Class requirements.
2) Required for: K-ME-C6/7 and K98ME6/7 engines with 11 and 14 cylinders incl. ME-GI variants.
All ME-C9/10 and ME-B9 engines incl. ME-GI variants.
All ME-C7/8 and ME-B8 engines with 5 and 6 cylinders incl. ME-GI variants.
Select one of the alternatives * Or shut down
Or alarm for low flow * Or shut down
Or alarm for overheating of main, crank and crosshead bearings, option: 4 75 134.
See also Table 18.04.04: Shut down functions for AMS and UMS
