MAN B&W 4.05

Page 3 of 9

MAN Diesel

198 57 97-7.5

MAN B&W 98-60 engines

178 63 81-7.0

Fig. 4.05.02: MAN Diesel & Turbo 1,500 kW TCS-PTG solution

320

1,363

3,345

Frame for powertrain and piping system

1,389

3,531
