Mandik FDMR - Design with Spring Return Actuator

6
Position:
1 Body – 1 damper 8
Thermo-electrical fuse ExPro-TT
2 Body – 2 damper 9 Inspection hole covering
3 Damper blade 10 Control lever
4 Electrical actuator Schischek ExMax-15BF 11 Pin with lever
5 Mechanical actuator Atex 12 Initiation button
6 Thermal fuse 13 Insulation partition (promat)
7 End switch
