Manitou E-E3 Series User Manual

3-11
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,
P = BLEED, R = REPLACE, V = DRAIN
PAGE
(1)
DAILY OR EVERY 10
HOURS SERVICE
EVERY 50 HOURS
SERVICE
EVERY 250 HOURS
SERVICE
EVERY 500 HOURS
SERVICE OR 6
MONTHS
EVERY 1000 HOURS
SERVICE OR 1 YEAR
EVERY 2000 HOURS
SERVICE OR 2 YEARS
EVERY 4000 HOURS
SERVICE
OCCASIONALLY
BRAKE
Brake oil level
3-20 C C <<< <<< <<< <<< <<<
Parking brake 3-25 C/A C/A <<< <<< <<< <<<
Parking brake lever mechanism 3-31 G G <<< <<< <<<
Parking brake mechanism on the transmission G** G** <<< <<< <<<
Brake oil V** <<< <<<
Brake system P** <<< <<<
Brake system pressure C** <<< <<<
Brake A** <<< <<<
STEERING
Steering
C** <<<
Steering swivel joints C**
CAB
Windscreen washer liquid level
3-21 C C <<< <<< <<< <<< <<<
Cab door 3-21 G G <<< <<< <<< <<< <<<
Cab ventilation filter (OPTION Air conditioning) 3-21/26 R N R <<< <<< <<< <<<
Heating block non-return valve 3-26 N N <<< <<< <<< <<<
Cab ventilation filters 3-32 N N <<< <<< <<<
Seat belt 3-37 C <<< <<<
Condition of the rear view mirrors C** <<< <<<
Structure C** <<< <<<
Air conditioning (OPTION) 3-39 N/C <<<
ELECTRICITY
Longitudinal stability limiter and warning device
3-15/45 C C <<< <<< <<< <<< <<< <<< XXX
Condition of wiring harness and cables C** <<< <<<
Lights and signals C** <<< <<<
Warning indicators C** <<< <<<
Front headlights 3-41 A
FRONT AXLE
Front wheels reducers pivots
3-22 G G <<< <<< <<< <<< G/C**
Front axle differential oil level 3-26 C C <<< <<< <<< <<<
Front wheels reducers oil level 3-26 C C <<< <<< <<< <<<
Front axle differential oil 3-32 V V <<< <<< <<<
Front wheels reducers oil 3-37 V V <<< <<<
Wear of front axle brake discs C**
Front wheels reducers universal joint C**
Front wheels reducers clearance C**
REAR AXLE
Rear wheels reducers pivots
3-22 G G <<< <<< <<< <<< G/C**
Rear axle oscillation 3-22 G G <<< <<< <<< G/C** <<<
Rear axle differential oil level 3-26 C C <<< <<< <<< <<<
Rear wheels reducers oil level 3-26 C C <<< <<< <<< <<<
Rear axle differential oil 3-32 V V <<< <<< <<<
Rear wheels reducers oil 3-37 V V <<< <<<
Wearing of rear axle brake discs C**
Rear wheels reducers universal joint C**
Rear wheels reducers clearance C**
CHASSIS
Stabilizers
MT 1030 S Turbo Série 5-E3 3-22 G G <<< <<< <<< <<< <<<
Structure C** <<< <<<
Bearings and articulation rings C** <<<
ATTACHMENTS
Forks wear
C** C** <<< <<< <<<
Attachment carriage C** <<< <<<
Condition of attachments C** <<< <<<
LIFT TRUCK
Tow the lift truck
3-41 XXX
Sling the lift truck 3-42 XXX
Transport the lift truck on a platform 3-43 XXX
(*): Every 10 hours during the first 50 hours, then once at 250 hours.
(**): Consult your dealer.
647083 EN (21/06/2011)
