Manitou E-E3 Series User Manual

2-8
REF PART NUMBER DESCRIPTION
1
193032 Cab compliance
2
223324 Patents
3
Consult your dealer Manufacturer’s plate
4
239595 Acoustic power
5
268491 Break fluid instruction
6
33460 Gear lever control
7
265284 Lifting ring on carriage (option)
8
184276 Forward/reverse lever control
9
290183 Bucket instruction on telescope
10
297733 Operating mode management instruction
11
291213 Fuses
12
240805 Reach chart sheet
13
Consult your dealer Load chart
14
258969 Manipulator function sheet (for MT 732 / MT932 only)
254040 Manipulator function sheet (for MT 1030 S Turbo only)
15
272040 Transmission cut-off switch function sheet
16
241621 Safety instruction sheet
17
294831 Reset procedure sheet (for MT 732 / MT932 only)
295054 Reset procedure sheet (for MT 1030 S Turbo only)
18
267425 Carriage lifting ring sheet (option MT 732)
267862 Carriage lifting ring sheet (option MT 932)
266915 Carriage lifting ring sheet (option MT 1030 S Turbo)
19
241645 Single side-shift carriage sheet (TSDL) (option MT 1030 S Turbo)
3
2
1
4
N$ 193032
CABINE CONFORME A :
CAB CONFORMS TO :
FOPS - ISO 3449
ROPS- ISO 3471
ANSI B 56.6
BREVETS - PATENTS
FR 93 14367
EP 0656 315
US PENDING
n$223324
MANITOU BF 44158 ANCENIS CEDEX FRANCE
N°283688
MODELE
MODEL
MODELLO
MODELO
SERIE
SERIES
SERIE
SERIE
N° de série
Serial Nr
Numero di serie
Número de serie
Masse à vide
Unladen mass
Numéro d'homologation
Homologation number
Numero d'omologazione
Contraseña homologacion
Capacité maxi nominale
Nominal maximum capacity
Capacità maxi nominale
Capacidad máximo nominal
Effort de traction
Tractive effort
Forza di traino
Esfuerzo de traccion
Massa a vuoto
Masa en vacio
Année de fabrication
Year of manufacture
Anno di fabbricazione
Año de fabricacion
Puissance ISO/TR14396
Power ISO/TR14396
Potenza ISO/TR14396
Potencia ISO/TR14396
Effort vertical max.
(sur accrochage remorque)
Vertical max. effort (on trailer hook)
Carico max. verticale (sul gancio di traino)
Esfuerzo vertical max. (sobre el gancho de remolque)
Pression des pneumatiques (Bar)
Tyre pressure (Bar)
Pressione per pneumatici (Bar)
Presion de los neumáticos (Bar)
kW
daN
Avant
Front
Anteriore
Adelante
Arrière
Rear
Posteriore
Trasero
kg
kg
daN
239595
3 - STICKERS AND PLATES IN THE CAB
