HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device Electronic
Lifting motions (boom retracted)
Unladen lifting s - m/mn 7,15 - 37,4
Laden lifting s - m/mn 11,5 - 23,3
Unladen lowering s - m/mn 5,2 - 51,5
Laden lowering s - m/mn 5,3 - 50,5
Telescoping motions (boom raised)
Unladen extending s - m/mn 12,1 - 12,7
Laden extending s - m/mn 12,3 - 12,9
Unladen retracting s - m/mn 9,4 - 16,6
Laden retracting s - m/mn 9,1 - 17,1
Tilting movements
Unladen digging s - °/s 2,7 - 46,5
Forward tilting unladen s - °/s 2,6 - 48,3
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground (except particular conditions)
Front unladen 1 km/h 4,4
2 km/h 7,1
3 km/h 15,0
4 km/h 25
Rear unladen 1 km/h 4,4
2 km/h 7,1
3 km/h 15,0
4 km/h 25,0
Standard attachment TFF
Weight with forks kg 165
Weight of forks (each one) kg 67,5
Rated capacity with standard attachment kg 3200
Tipping load at maximum reach on tyres kg 673
Distance from the centre of gravity from the load to the lug of the forks mm 500
Standard lifting height mm 9000
Lift truck weight without attachment kg 7455
Lift truck weight with standard attachment
Unladen kg 7755
At rated load kg 10955
Weight per axle with standard attachment (transport position)
Front unladen kg 3335
Rear unladen kg 4420
Front rated load kg 9195
Rear rated load kg 1760
Weight per axle with standard attachment (boom extended)
Front rated load kg 7655
Rear rated load kg 600
Authorised gross vehicle weight daN 23755
Contact pressure on the ground for the whole surface of each stabilizer
at maximum load when tilting
kg/cm2 -
Drag strain on the coupling hook
Unladen (sliding) daN 6320
At rated load (transmission setting) daN 9240
Pull strain with open carrier
(according to standard ISO 8313) daN 7400
HYDRAULIC CIRCUIT
Hydraulic pump
Type Gear pump with flow divider
1st casing 2nd casing
Capacity cm3 22 22
Max. rating capacity unladen l/mn 52 52
Flow rate at 1600 rpm l/mn 35 35
Filtration
Return µm 15 15
Suction µm 125 125
Maximum service pressure bar 250
Telescoping circuit bar 190 / 250
Lifting circuit bar 250 / 250
Tilt circuit bar 250 / 190
Attachment circuit bar 250
Steering circuit bar 140
