Manitou E-E3 Series User Manual

2-19
PRESSURE
(bar)
LOAD
(kg)
PRESSURE ON THE CONTACT SURFACE
(kg/cm2)
AREA OF THE CONTACT SURFACE
(cm2)
HARD SOIL LOOSE SOIL HARD SOIL LOOSE SOIL
MICHELIN
460/70R24
XMCL 159A8
TUBELESS
3,4
450 1,35 0,37 406 1438
500 1,38 0,39 424 1457
750 1,51 0,50 511 1550
900 1,59 0,56 564 1605
1600 1,96 0,85 809 1866
1650 1,99 0,87 827 1885
1700 2,01 0,89 843 1903
2050 2,16 1,00 947 2033
2100 2,18 1,02 962 2051
2200 2,22 1,05 992 2088
4550 2,90 1,53 1568 2962
4600 2,91 1,54 1580 2961
4750 2,95 1,57 1617 3027
4800 2,97 1,58 1629 3055
400/80-24
156A8 IND POWER CL
TUBELESS
3
750
900
1600
1650
2100
2200
4550
4600
3,4
450
500
1700
2050
4750
4800
15,5R25
XHA
TUBELESS
3,5
450 3,88 2,21 134 226
500 3,91 2,23 143 244
750 4,11 2,29 186 332
900 4,23 2,33 212 385
1600 4,77 2,52 334 632
1650 4,81 2,54 343 650
1700 4,84 2,55 351 667
2050 4,98 2,60 412 789
2100 5,00 2,60 419 806
2200 5,04 2,62 436 841
4550 5,65 2,92 805 1558
4600 5,66 2,92 813 1573
4750 5,70 2,94 837 1619
4800 5,71 2,95 844 1634
647083 EN (21/06/2011)
