Manitou E-E3 Series User Manual

2-22
DIMENSIONS AND LOAD CHART
MT 732 Série E-E3
A
(mm)
1200
B
(mm)
2560
C
(mm)
1444
C1
(mm)
1537
D
(mm)
4767
D1
(mm)
4860
D2
(mm)
3894
E
(mm)
5967
F
(mm)
1846
F1
(mm)
1846
G
(mm)
455
G1
(mm)
440
G2
(mm)
440
I
(mm)
763
J
(mm)
865
K
(mm)
1040
L
(mm)
45
N
(mm)
1690
O
(mm)
125
P2
(°)
47,5
P3
(°)
53
R
(mm)
3460
S
(mm)
7591
T
(mm)
3555
U1
(mm)
2300
U2
(mm)
2550
V
(mm)
4805
V1
(mm)
1250
V2
(mm)
3667
W
(mm)
2260
Y
(°)
11,9
Z
(°)
113,8
647083 EN (21/06/2011)
