CHARACTERISTICS
I.C. ENGINE
- Type
MT 523 Série B-E2
MT 523 MONO-ULTRA Série B-E2
MLT 523 Turbo Série B-E2
MLT 523 Turbo MONO-ULTRA Série B-E2
MT 620 Série B-E2
- Number of cylinders
- Number of strokes
- Suction
- Injection system
- Ignition sequence
- Clearance of rocker valve (cold)
. Inlet
. Exhaust
- Capacity
- Bore
- Stroke
- Compression ratio
- Nominal rating loaded
- Rating slow unladen
- Max. rating unladen
- Power ISO/TR 14396
- Maximum torque ISO/TR 14396
- Air cleaner
COOLING CIRCUIT
- Type
- Fan
. Number of blades
. Diameter
- Thermostat
. Start opening
. Full opening
HYDROSTATIC TRANSMISSION
HYDROSTATIC PUMP
- Type
- Gear reverser
. Number of forward gears
. Number of reverse gears
- Main pump
. Max. / Mini displacement
. Max. flow rate
. Working pressure
- Boost pump
. Displacement
. Max. flow rate
. Boost pressure Max. R.P.M.
HYDROSTATIC MOTOR
- Type
. Max. / Mini displacement
PERKINS 1103C-33 DC38182
PERKINS 1103C-33 DC38182
PERKINS 1103C-33T DD38220
PERKINS 1103C-33T DD38220
PERKINS 1103C-33 DC38182
1103C-33 1103C-33T
3 in line 3 in line
44
Natural Turbocharged
Direct Direct
1.2.3. 1.2.3.
0,20 mm 0,20 mm
0,45 mm 0,45 mm
3300 cm3 3300 cm3
105 mm 105 mm
127 mm 127 mm
19,2/1 18,25/1
2200 rpm 2200 rpm
900
±10
rpm 900
±10
rpm
2350 rpm 2350 rpm
58 cv/43 kw 75 cv/55 kw
222 Nm à 1400 rpm 291 Nm à 1400 rpm
Sec 3 µm Sec 3 µm
By water
Puller
10
508 mm
79 °C/84 °C
93 °C
MANNESMANN REXROTH A4VG56DA1D7/32R with variable cubic
capacity and with automatic power governor
Electromagnetic 12V
1
1
0 to 56 cm3/r
119,9 L/mn
475 Bar
37 cm3
87 L/mn
26 Bar (transmission in neutral)
MANNESMANN REXROTH A6VM80DA1/63W with variable cubic capacity
28 to 80 cm3/r
