4 - 8
C - ATTACHMENT WITHOUT HYDRAULICS AND HYDRAULIC LOCKING
DEVICE (OPTION)
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MLT 633/730 -120 LS POWERSHIFT Série A
MLT 730 Turbo POWERSHIFT Série A
TAKING UP AN ATTACHMENT
- Ensure that the attachment is in a position facilitating the locking to the carriage. If it is
not correctly oriented, take the necessary precautions in order to move it safely.
- Check that the rods on the locking cylinder are retracted (Fig. A).
- Place the lift truck with the jib lowered in front of and parallel to the attachment, tilt the
carriage forwards (Fig. B).
- Bring the carriage under the locking tube of the attachment, slightly lift the jib, incline
the carriage backwards in order to position the attachment (Fig. C).
- Lift the attachment off the ground to facilitate locking.
HYDRAULIC LOCKING (OPTION)
- Put the valve in position A (Fig. D), that is to say, the hydraulic circuit of the attachment
locking open.
- Press button 1 (Fig. E) on the distributor lever to completely lock the attachment to the
carriage.
- Close the valve in position B (Fig. D), that is to say, the hydraulic circuit of the
attachment locking closed.
Always close the valve in position B (Fig. D) after the locking of the attachment, in
order to avoid accidental unlocking and use the attachment safely.
HYDRAULIC RELEASING (OPTION)
- Put the valve in position A (Fig. D), that is to say, the hydraulic circuit of the attachment
locking open.
- Press button 2 (Fig. E) on the distributor lever to completely unlock the attachment.
LAYING AN ATTACHMENT
- Proceed in the reverse order of paragraph TAKING UP AN ATTACHMENT while
making sure you place the attachment flat on the ground and in closed position.
INACTIVATE THE HYDRAULIC RELEASE CONTROL
You can change an attachment without leaving the control post, by cutting the electricity
supply to the hydraulic control.
- Leave the valve in position A (Fig. D).
- Use switch 3 (Fig. F) to cut the electricity supply to the hydraulic control. The circuit is
out of action when indicator 4 (Fig. F) is on.
Always cut the electrical power to the circuit using switch 3 (Fig. F) after each change
of attachment to avoid involuntary release and use the attachment in complete
safety.
B
C
A
D
A
B
