26 - LEVEL INDICATORS
A - TILTING INDICATOR (OPTION)
When the two marks are aligned, the chassis is
parallel with the front axle.
B - SPIRIT LEVEL
Enables the operator to check that the lift truck
is in the horizontal position.
27 - DOOR OPEN LEVER
28 - DOOR CLOSE HANDLE
29 - ELECTRIC WINDOW SWITCH
30 - SIDE STORAGE SPACE
31 - ROOF LIGHT (CAB "COMFORT")
32 - HANDLE FOR REAR WINDOW OPENING
EMERGENCY EXIT
- Use the rear window as an emergency exit, if
it is impossible to leave the cab by the door.
33 - HANDLE FOR REAR WINDOW CLOSING (CAB "COMFORT")
34 - STEERING WHEEL ADJUSTMENT LEVER (OPTION)
This handle enables the angle and height of the steering wheel to be adjusted.
- Pull the knob backwards.
- Adjust the steering wheel to the desired position.
- Push the knob back to lock the steering wheel in position.
A
B
CAB "COMFORT"
