Manitou PRIVILEGE E3 - Page 185

IT
4
89
MRT 1850 - 2150 - 2540
H
G
I
D
R'
R
78˚
17˚
E
F
B
180˚
A
C L
AERIAL JIB
CARATTERISTICHE - CHARACTERISTICS - EIGENSCHAFTEN
DESCRIZIONE
DESCRIPTION
BESCHREIBUNG
INGOMBRI
OVERAL LENGTH
PLATZBEDARF
(mm)
AERIAL JIB 300 Kg
CAPACITA’
CAPACITY
FASSUNGSVERMÖGEN
A C D
2500
B
1200 1000 5230
E
2650
F
4447
G
5910
H
6140
I
390
L
450
R
2670
R’
4300
PESO
WEIGHT
GEWICHT
930 Kg
EN
DE
AERIAL JIB AERIAL JIB
