Rigging work
12.8 Rigging the auxiliary hoist
12 - 92 3 112 993 en Operating manual GMK 6400
12.07.2013
12.8.2 Slinging points and transport
Slinging points
The auxiliary hoist is equipped with four sling-
ing points (1).
• Only attach the auxiliary hoist to the slinging
points (1).
The catcher is fitted with two slinging points
(1), on which the catcher is slung together with
the upper hook block.
• Only attach the catcher to the slinging points
(1).
G
Risk of accident if used improperly
Only attach the auxiliary hoist to the slinging points provided. Always use
lifting gear with sufficient lifting capacity;
à Dimensions and weights of
removable parts
– Auxiliary hoist, p. 1 - 11.
