Part Number STH025 11/16 131
SINGLE EVAPORATOR, DUAL EXPANSION VALVE
SELF CONTAINED AIR, WATER & REMOTE CONDENSER
Operational Analysis 1 2 3 4
Ice Production Air-Temperature Entering Condenser __________________
Water Temperature Entering Ice Machine _______________
Published 24 hour ice production _____________________
Calculated (actual) ice production _____________________
NOTE: The ice machine is operating properly if the ice fill patterns is normal and ice production is within 10%
of charted capacity.
Installation and
Water System
All installation and water related problems must be corrected before proceeding with table.
Ice Formation Pattern
Top or 1
Side_________
Bottom or 1
Side_________
Ice formation is extremely
thin on outlet of
evaporator
-or-
No ice formation on one
side or Top or Bottom of
evaporator
Ice formation is extremely
thin on outlet of one
side or Top or Bottom of
evaporator
-or-
No ice formation on entire
evaporator
Ice formation normal
-or-
Ice formation is extremely
thin at inlet of one side
or Top or Bottom of
evaporatorr
-or-
No ice formation on entire
evaporator
Ice formation normal
-or-
No ice formation on entire
evaporator
To Next Page
