Manitowoc Indigo ID0502A User Manual

Part Number STH025 11/16 265
I1800N
Remote Air-Cooled Condenser Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
Water Temperature °F/°C
50/10 70/21 90/32
70/21 9.2-10.5 10.1-11.5 10.0-12.4
0.75-2.0
80/27 9.6-11.0 10.6-12.1 11.5-13.0
90/32 10.2-11.6 11.2-12.8 12.2-13.9
100/38 11.0-12.5 12.1-13.8 13.3-15.1
110/43 11.9-13.6 13.2-15.0 14.7-16.6
1 Times in minutes
24 HOUR ICE PRODUCTION
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
50/10 70/21 90/32
70/21 1775 1635 1535
80/27 1705 1565 1465
90/32 1625 1495 1385
100/38 1525 1395 1285
110/43 1415 1295 1175
1 Based on average ice slab weight of 13.20- 14.80 lb.
OPERATING PRESSURES
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
50/10 230-265 38-24 100-160 70-85
70/21 240-265 40-26 110-170 70-90
80/27 250-275 45-28 110-180 70-95
90/32 250-300 52-29 110-180 70-95
100/38 275-335 55-31 110-185 75-100
110/43 310-385 55-32 120-190 80-110
1 Suction pressure drops gradually throughout the freeze cycle
