Part Number STH025 11/16 59
Cursor: A cursor (flashing rectangle) is used within lines
where actual settings can be adjusted. In these screens,
use the Up and Down arrows to make changes to the
value underlined. Move the cursor from digit to digit
using the Right and Left arrows. Use the Checkmark to
move the cursor down one line. Exit and re-enter the
screen to start again at the top.
▼
Day/Mo/Yr ( )
12 Hour ( )
24 Hour ( )
Selections: When parentheses ( ) appear, they indicate
a selection is available by pressing Checkmark while the
line is highlighted. If the choice is exclusive, selecting it
with the Checkmark will uncheck another selection. That
is, in the above Time Config example, selecting Day/Mo/
Yr will deselect Mo/Day/Yr.
To Next Page
