Event Log Detail
E-L
o
g
Dis
p
la
y
Text Error Descri
p
tion
Definition
E01
Lon
g
Freeze
Long Freeze
6 consecutive 60 Minute Freeze c
y
cles = shut down and flash the SL#1 li
g
ht on board
E02
Long Harvest
Long Harvest
3 consecutive - 3.5 Minute Harvests logs SL#2 in memory, but runs until 500 long harvest cycles occur.
E03
Power Loss
Power Supply (Event Log only -
No Alert)
When power is interrupted to the ice machine the control board will log the event in the ELOG and stam
p
the loss of
p
ower on
p
ower-u
p
.
E04
Hi Cnd Temp or
Wtr Cnd Fault
Air Condenser High temp, or
water Condenser High
temperature G Board Rev 4.017 - Alert only after 10 consecutive trips
1). Liquid Line Temperature too High for Self-contained Air Cooled Ice machine = Air Cooled
Condenser Fault 2). Liquid Line Temperature too High for Self-contained Water Cooled ice machine = Water Cooled Condenser Fault
E05
HPC Fault
High Pressure Cutout (HPC)
The high pressure cutout switch (HPCO) opened 3 times in 4 hour period
E06Spare E07
Starving TX
V
Starving Evaporator for single
TXV or low on charge
10 consecutive occurrences where the Difference of the Av erage evaporator inlet (T3) and outlet (T4)
is greater than 12°F in the last 1 minute of the freeze cycle (ELOG-E07)
E08
TXV Faul
t
Air/Water Only TXV malfunction in dual circuit/
single evaps (TXV Fault)
E09
Flood Evap 1
Flooding evaporator for single circuit single evaporator (flooding
evap)
E10
Flood Evap 2
Flooding evaporator for dual TXV dual circuit / single evaporator (Flooding Evap)
Detail Event Log Service Definition
10 consecutive occurrences where the Difference of the Average evaporator inlet (T3) and outlet (T4)
is greater than 12°F in the last 1 minute of the freeze cycle (ELOG-E07)
G Board Rev 4.017 - Event Log only no alert
Average compressor discharge line temperature last 6 seconds of Prechill +50°F (T1) compared to
average of first 6 minutes of freeze cycle (T2), is less than 1.05°F
Average compressor discharge line temperature last 6 seconds of Prechill +50°F (T1) compared to
average of first 6 minutes of freeze cycle (T2), is less than 1.05°F
