34 Part Number 000014141 Rev 07 2/20
Installation Section 2
Heat of Rejection
Model Peak Average
IF0500N 6900 6100
IT0500N 6900 6100
IF0600N 13900 9000
IF0900N 16000 13000
IT1200N 24500 20700
IT1500N 27000 23000
IT1900N 30500 26100
Refrigerant Charge
The ice machine model/serial tag lists the
refrigerant amount. Remote condensers
and line sets contain a vapor charge only.
Model Amount Type
IF0500N 6.0 lbs - 2.72 kg R404A
IT0500N 6.0 lbs - 2.72 kg R410A
IF0600N 6.5 lbs - 2.95 kg R404A
IF0900N 7 lbs - 3.18 kg R404A
IT1200N 7.5 lbs - 3.40 kg R410A
IT1500N 7.5 lbs - 3.40 kg R410A
IT1900N 8.0 lbs - 3.63 kg R410A
Model/serial plate information overrides all data
listed in this chart.
Quick Connect Fittings
The ice machine and line sets come with
quick connect fittings. It is recommended
that matching quick connects (available
through Manitowoc Distributors K00129)
be installed in the multi-circuit condenser,
and that a vapor “holding” charge, 5 oz.
(150 ml), of proper refrigerant be added to
the condenser prior to connection of the
ice machine or line set to the condenser.
