7. Refer to chart and record refrigeration operating data.
Freeze Data* HP¹ LP² LLT³
1 minute after water starts
flowing over the evaporator
Middle of the freeze cycle
End of the freeze cycle
Harvest Data* HP¹ LP² LLT³
30 seconds into harvest
2.5 minutes into harvest
Dual Evaporators – after first
evaporator and before the
second evaporator drops ice
*Record Total Freeze Time and Harvest time
¹ High side refrigeration system pressure at the ice machine
discharge line
²Low side refrigeration system pressure taken at the ice
machine suction line
³Liquid line temperature at the ice machine - T1 on
touchscreen (service/diagnostics/temperature sensors)
