Specifications
Drums
Basic machine is equipped with an independent main
drum assembly and independent lung/aux drum
assembly mounted in the boom butt. Each drum is
driven by a variable-displacement hydraulic motor
through a planetary reduction. Drums are grooved for
28 mm wire rope. Main hoist has 36,760 lb linepull
on all layers with a 26.77" drum diameter; lung/aux
drum has 30,000 lb linepull on all layers with a 26.77"
drum diameter.
Powered hoisting/ lowering operation with automatic
spring applied, hydraulically released multi-disc brakes,
and drum rotation indicators standard.
Basic machine is equipped with a rigging winch
mounted in the boom butt. Drum utilizes 8 mm wire
rope with 2250 lb max linepull capability.
Optional: auxiliary hoists – Rotating bed mounted,
can be tted with one or two auxiliary drums
grooved for 28 mm wire rope, and both having
36,760 lb linepull on all layers. ese two drums
can be used independently or in tandem to suit a
variety of lift applications.
Optional: freefall hoists – Rotating bed mounted,
can be tted with one or two free fall equipped
drums grooved for 28 mm wire rope. Freefall
function is controlled by wet disk brake manually
applied by foot pedal with locking latch in
operator’s cabin. Operator may select free-fall or
powered lowering mode using a selector switch in
the cab.
Moving mast system
Independent boom hoist consists of a single drum
grooved for 26 mm (1") diameter wire rope. Includes
1394 ft of 26 mm diameter wire rope to accomodate 24
part live mast reeving.
Drum is powered by a variable displacement hydraulic
motor coupled to an internal spring applied, hydraulically
released multi-disc brake multi-disc brake and planetary
gearbox equipped with ratcheting pawl and drum
rotation indicators.
Live mast system assembly module includes live mast,
boom hoist drum and rear sheave nest. e assembly
weighs 19,325 lbs and may be removed from the
rotating bed for an upperworks module transport
weight reduction.
Upperworks
Engine
Cummins Model QSG-12 diesel, 11.8 liter
displacement, inline 6 cylinder, 450 BHP @1800
governed RPM. Emissions Level: U.S. EPA/ CARB Tier
4 Final/ EU Stage IV Compliant.
Included are engine block heater (240 V), engine oil
pan heater (240 V), air intake grid heater, disconnect
clutch for cold weather starting, exhaust after treatment,
variable speed hydraulic cooling fan, hydraulic oil cooler,
radiator, charge air cooler, and fuel cooler.
Also included are two 12 volt maintenance-free, Group
8D batteries, 1375 CCA at - 0°F, 24 volt starting and
110 amp alternator.
Single diesel fuel tank is 264 gal capacity complete with
physical level indicator on tank and electronic level
indicator in the operator’s cabin.
Optional: Cold-weather package including heaters
for uids and batteries.
Crane Control System
e Crane Control System oers a user-friendly
interface, two full graphic displays mounted
horizontally for better visibility, a jog dial for easier data
input and ergonomic joysticks.
Hydraulic system
Ecient, independent, full power multi-functional
control is achieved in all operating modes through
a combination of open and closed loop system
optimized by Manitowoc’s proprietary onboard
Crane Control System.
145 gal hydraulic reservoir is equipped with sight gauge,
breather, clean out access, 100 micron mesh internal
strainers, and 40 micron inlet screens. Primary ltration
system is equipped with 8 micron absolute lters.
