Part Number 80-1505-3 6/11 45
A. LINE SET LENGTH
100 feet (30.5 m) Length: The maximum measured
length the line set can be.
The receiver is designed to hold a charge sufficient to
operate the ice machine in ambient temperatures
between -20°F (-28.9°C) and 130°F (54.4°C)*, with
line set lengths of up to 100 feet (30.5 m).
*CVD685/CVD1185/CVD2085/CVD3085 =
-20°F to 120°F (-29°C to 49°C)
CVD1486 = 50°F to 110°F (10°C to 43°C)The
maximum amount of lineset which can be exposed on
the rooftop is 25% of the total length of the lineset.
QuietQube
®
Ice Machines will not function with line
sets greater than 100 ft. (30.5 m). Do not attempt to
go beyond this distance and add refrigerant charge
to compensate!
QuietQube® ice machines will not function with line
sets greater than 100 feet (30.5 m). Do not attempt
to go beyond this distance and add refrigerant
charge to compensate!
