Mantis “E” System - Page 11

KEY # DESCRIPTION PART # QTY
1 GEAR CASE-ASS’Y 331186 1
2 GEAR CASE 331187 1
3 BEARING 609 331146 1
4 GEAR 331188 1
5 MAIN GEAR HOUSING SHAFT 331189 1
6 BEARING 6201 331190 1
7 SNAP RING 331191 1
8 SEAL 331192 1
9 GEAR CASE COVER 331193 1
10 PINION 331194 1
11 BEARING 61900 331195 1
12 BEARING 61900Z 331196 1
13 SNAP RING 331197 1
14 SNAP RING 331198 1
15 SCREW W/WASHERS M5X12 331560 1
16 SCREW W/WASHERS M5X30 331525 2
17 SCREW M8X12 331526 1
18 WASHER 331527 1
19 CUTTING HEAD 4” 331199 1
20 TRIMMER LINE 331200 1
21 SPOOL 331201 1
22 SPOOL LOCKING PART 331202 1
23 RATCHET 331203 1
KEY # DESCRIPTION PART # QTY
24 SPRING 331204 1
25 PLATE 331205 1
26 SPOOL HOLDER 331206 1
27 CENTER INSERT 331207 1
28 GUARD ASS'Y
WITH CLAMPING PLATE 331208 1
29 GUARD SUB-ASSEMBLY 331209 1
30 CLAMPING PLATE 331210 1
31 SCREW M5X16 331528 3
32 LOCK WASHER 331529 3
33 NUT M5 331530 2
34 CUTTING BLADE 331211 1
35 SCREW M5X16 331531 2
36 INTERNAL SHAFT 628X7MM 331212 1
37 SPACER 331213 1
38 INTERNAL SHAFT ADAPTER 331214 1
39 OUTER SHAFT 024X623MM 331215 1
40 WARNING LABEL 331179 1
41 LOCK WASHER 331532 2
42 FLAT WASHER 331533 2
43 BUSHING 331294 1
44 PROTECTIVE SLEEVE 331295 1
10
Line Trimmer “E” System Parts List
