Antenna installation schematic
Front view
Goggles antenna installation diagram Display antenna installation diagram
Side view
Goggles antenna installation diagram Display antenna installation diagram
(When installing the antenna, the pitching Angle of the antenna
should be adjusted appropriately according to the flying habits, so
that the receiving antenna is perpendicular to the ground when
the UAV is in normal flight)
