Marantz PM-11S3 Service Manual

66
Ref No. Part No. Part Name Remark Q'ty New
S3504 00D2140208003 RELAY(NA24W-K)
S3505 00D2140208003 RELAY(NA24W-K)
S3506 00D2140208003 RELAY(NA24W-K)
S3507 00D2140208003 RELAY(NA24W-K)
S3508 00D2140208003 RELAY(NA24W-K)
S3601 00D2140208003 RELAY(NA24W-K)
S3602 00D2140208003 RELAY(NA24W-K)
S3801 00D2140208003 RELAY(NA24W-K)
S3802 00D2140208003 RELAY(NA24W-K)
S4001 00D2140208003 RELAY(NA24W-K)
S4002 00D2140208003 RELAY(NA24W-K)
S5501 00D2140208003 RELAY(NA24W-K)
z
S8901 66105000300AS POWER SWITCH (TV-5)
Z3007 00MKH22AJ1020 HDAM-SA3D
Z3008 00MKH22AJ1020 HDAM-SA3D
Z3009 00MKH22AJ1020 HDAM-SA3D
Z3010 00MKH22AJ1020 HDAM-SA3D
Z3011 00MKH22AJ1020 HDAM-SA3D
Z3012 00MKH22AJ1020 HDAM-SA3D
Z3013 00MKH22AJ1020 HDAM-SA3D
Z3014 00MKH22AJ1020 HDAM-SA3D
Z3015 00MKH22AJ1020 HDAM-SA3D
Z3016 00MKH22AJ1020 HDAM-SA3D
Z4029 00MKH22AJ1020 HDAM-SA3D
Z4030 00MKH22AJ1020 HDAM-SA3D
Z4511 00MKH22AJ1020 HDAM-SA3D
Z4512 00MKH22AJ1020 HDAM-SA3D
Z4513 00MKH22AJ1020 HDAM-SA3D
Z4514 00MKH22AJ1020 HDAM-SA3D
Z4515 00MKH22AJ1020 HDAM-SA3D
Z4516 00MKH22AJ1020 HDAM-SA3D
Z5001 00MKH22AJ1020 HDAM-SA3D
Z5002 00MKH22AJ1020 HDAM-SA3D
Z5003 00MKH22AJ1020 HDAM-SA3D
Z5004 00MKH22AJ1020 HDAM-SA3D
Z5005 00MKH22AJ1020 HDAM-SA3D
Z5006 00MKH22AJ1020 HDAM-SA3D
Z5501 00MKH22AJ1020 HDAM-SA3D
Z5502 00MKH22AJ1020 HDAM-SA3D
Z5503 nsp 13P PLUG(C125Z1)
Z5504 nsp 13P PLUG(C125Z1)
Z5505 00MKH22AJ1020 HDAM-SA3D
Z5506 00MKH22AJ1020 HDAM-SA3D
Z5507 nsp STYLE PIN

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
