Marantz PM-11S3 Service Manual

68
Ref No. Part No. Part Name Remark Q'ty New
z
D8012 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8013 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8014 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8015 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8016 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8017 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8018 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
D8101 20105001130AS 1SS133(HOMI)
D8102 20105001130AS 1SS133(HOMI)
D8103 20105001130AS 1SS133(HOMI)
D8104 20105001130AS 1SS133(HOMI)
D8107 20105001130AS 1SS133(HOMI)
D8108 00D2760683901 UDZS5.6B-TE17 +C
z
D8109 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8110 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8111 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8112 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8113 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8114 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8115 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8116 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
D8117 00MHZ30017210 UDZS 10B (TE-17) ROHM
D8118 00MHZ30017210 UDZS 10B (TE-17) ROHM
D8119 00D2760683985 UDZS11B-TE17
D8120 00D2760683985 UDZS11B-TE17
z
D8501 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8502 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8503 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8504 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8505 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8506 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
z
D8507 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
D8508 20105001130AS 1SS133(HOMI)
D8509 20105001130AS 1SS133(HOMI)
D8510 00D2760683985 UDZS11B-TE17
z
D8511 00MHD20055100 !SHOTTKY 11EQS10 1A 100V
D9001 20105001130AS 1SS133(HOMI)
D9002 20105001130AS 1SS133(HOMI)
D9003 20105001130AS 1SS133(HOMI)
D9004 20105001130AS 1SS133(HOMI)
D9005 20105001130AS 1SS133(HOMI)
D9006 20105001130AS 1SS133(HOMI)
D9007 20105001130AS 1SS133(HOMI)
D9008 20105001130AS 1SS133(HOMI)
D9009 20105001130AS 1SS133(HOMI)
Q6001 00D2710314903 KTA1024-Y-AT/P
Q6004 00D2730471907 KTC3206-Y-AT/P
Q6009 00D2710314903 KTA1024-Y-AT/P
Q6010 00D2730471907 KTC3206-Y-AT/P
Q6011 00D2710314903 KTA1024-Y-AT/P
Q6012 21105001420AS KTA1360-Y-U/PH *
Q6013 21305001420AS KTC3423-Y-U/PH *
Q6014 00D2730471907 KTC3206-Y-AT/P

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
