Marcrist DDM2 - Page 14

12
WWAARRNNIINNGG
-
RReeaadd aallll ssaaffeettyy wwaarrnniinnggss ddeessiiggnnaatteedd bbyy tthhee ssyymmbbooll aanndd
aallll iinnssttrruuccttiioonnss..
Failure to follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
TToorrqquuee lliimmiittiinngg cclluuttcchh
The DDM2 - 230 is equipped with a torque-limiting clutch that reduces the maximum
torque reaction transmitted to the operator in case of jamming of a core bit. This feature
also prevents the gearing and electric motor from stalling. The torque-limiting clutch has
been factory-set.
CCEE--DDeeccllaarraattiioonn ooff ccoonnffoorrmmiittyy
Marcrist declares that the DDM2 - 230 Drilling Machine conforms to all current
standards and directives EN60745-1: 2006, EN60745-2-1: 2003 +A11: 2007,
EN55014-1: 2006, EN55014-2/A1: 2001, EN61000-3-2: 2006, EN61000-3-11:
2000, 98/37/EC, 2006/95/EC, 2004/108/EC. A detailed certificate of conformity
is available upon request.
RReeccyycclliinngg
According to WEEE directive 2002/96/EC, old machinery should be returned
for recycling or safe disposal when they eventually become to be thrown away
(see symbol on nameplate of the drill). Separate collection of used products and
packaging allows materials to be recycled and used again. Re-use of recycled materials
helps prevent environmental pollution and reduces the demand for raw materials.
Ensure that the old tool is returned to Marcrist International Ltd and does not end up in
unsorted municipal solid waste.
T
T
e
e
c
c
h
h
n
n
i
i
c
c
a
a
l
l
d
d
a
a
t
t
a
a
D
D
D
D
M
M
2
2
-
-
2
2
3
3
0
0
V
oltage 230 V
P
ower Input 1500 W
N
o load speed
1st gear 950 min
-1
2nd gear 2100 min
-
1
Maximum drilling Gear Wet Dry
d
iameter with 1 ø53-200mm ø108-200mm
diamond core bits 2 ø22-52mm ø22-107mm
Outer thread 1
1
/
4
” UNC (32mm) Inner thread
1
/
2
” BSP (19mm)
Spindle thread
Side handle clamp 60 mm
Weight 6.9 kg
TTeecchhnniiccaall DDaattaa
Maximum diameter shown on the
label only applies to Marcrist
core drills. By using low quality
core drills the maximum usable
diameter will be reduced.
