GSE
GSE GSE-O
TA B D E F D E F D* EFD* EF
kW kW mbar m3/h mm mbar m3/h mm mbar kg/h mm mbar kg/h mm
18 20,4 22,7 12,0 2,7 2,2 8,0 2,4 2,2 37 1,76 1,22 30 1,79 1,22
21 21,8 24,2 14,0 3,0 2,2 9,3 2,6 2,2 = = = = = =
24 25,1 27,9 12,0 3,3 2,2 8,0 2,9 2,2 37 2,17 1,22 30 2,20 1,22
28 27.2 30,2 14,0 3,6 2,2 9,3 3,1 2,2 = = = = = =
33 30,2 33,5 12,0 4,0 2,2 8,0 3,5 2,2 37 2,60 1,22 30 2,64 1,22
37 32,7 36,3 14,0 4,4 2,2 9,3 3,8 2,2 = = = = = =
44 40,2 44,7 12,0 5,4 2,2 8,0 4,7 2,2 37 3,47 1,22 30 3,53 1,22
49 43,6 48,4 14,0 5,9 2,2 9,3 5,1 2,2 = = = = = =
55 50,2 55,8 12,0 6,6 2,2 8,0 5,8 2,2 37 4,33 1,22 30 4,40 1,22
59 54,5 60,5 14,0 7,1 2,2 9,3 6,3 2,2 = = = = = =
66 60,3 67,0 12,0 8,0 2,2 8,0 7,0 2,2 37 5,21 1,22 30 5,28 1,22
74 65,3 72,6 14,0 8,7 2,2 9,3 7,6 2,2 = = = = = =
88 80,4 89,3 12,0 10,6 2,2 8,0 9,3 2,2 37 6,94 1,22 30 7,04 1,22
98 87,1 96,8 14,0 11,6 2,2 9,3 10,1 2,2 = = = = = =
104 95,8 106,5 = = = 11,3 11,1 2,2 = = = = = =
104 91,8 102,0 15,8 12,5 2,2 = = = = = = = = =
(1)
(2)
(2/3)
BE; NL AT; BE; CZ; DE; DK; ES; FL; FR; GB;
GR; HU; IE; IT; LU; PL; PT; SE
*
= FR; GB; HU; IE; IT;
LU; PL; PT: 37 mbar
*
= DK; ES; FI; GR; NO; SE: 30 mbar
G25 (25 mbar) G20 (20 mbar) G31 (37/50 mbar) G30 (30/50 mbar)
*
= BE; CZ; NL: 50 mbar
*
= AT; DE: 50 mbar
TCD E F GH J K LMNO
mm mm mm mm mm mm mm mm mm mm mm mm
18 40.0 100.0 = = 45.0 100.0 = = 40.0 100.0 = =
21 45.0 75.0 = = 50.0 75.0 55.0 55.0 40.0 100.0 = =
24 52.5 85.0 55.0 55.0 62.5 85.0 55.0 55.0 45.0 75.0 55.0 55.0
28 55.0 75.0 55.0 55.0 75.0 87.0 55.0 55.0 50.0 75.0 55.0 55.0
33 55.0 100.0 = = 70.0 80.0 52.0 52.0 52.5 60.0 = =
37 65.0 80.0 = = 80.0 60.0 50.0 50.0 60.0 80.0 56.0 56.0
44 60.0 45.0 55.0 55.0 70.0 55.0 55.0 55.0 55.0 65.0 55.0 55.0
49 67.5 45.0 55.0 55.0 76.0 34.0 55.0 55.0 60.0 65.0 55.0 55.0
55 57.5 44.0 = = 60.0 44.0 75.0 80.0 55.0 44.0 = =
59 65.0 44.0 = = 70.0 44.0 70.0 75.0 60.0 44.0 = =
66 65.0 50.0 80.0 80.0 70.0 50.0 75.0 = 62.5 50.0 80.0 80.0
74 77.5 50.0 75.0 75.0 85.0 50.0 73.0 73.0 75.0 50.0 = =
88 97.5 45.0 75.0 = 107.5 30.0 80.0 80.0 97.5 70.0 = =
98 110.0 26.0 75.0 = 133.0 26.0 70.0 75.0 107.5 55.0 = =
104 120.0 26.0 = = 133.0 26.0 = = ====
I
II
III
E/J/N
F/K/O
C/G/L
D/H/M
