Mark MBAR 120 - Page 3

UP
DOWN
INC
DEC
MBAR 120
Our DMX indoor MBAR 120 ( 8 sections) offers many possibilities to achieve the effects
which you want. The rolling and chasing effects are very good. It is designed for the stages,
disco, night clubs etc, even the building halls.
1. Weight: 3kg
2. Dimensions: 1000*70*90 mm
3. Power input: AC100-220V/50-60Hz
4. Consumption: 125W
5. LEDS: 80 1.5W 3IN1 LEDs
6. Beam angle: 40 degree
7. 3 pin female XLR socket and 3 pin male XLR socket
10. Built-in microphone
11. Black aluminum material
12.Working place: indoor, temperature:-20℃~45 ,humidity:0%-90%
13. LED display for easier operation
14.Built-in programs, stand alone, DMX mode, music active, static color
15. 6 selectable DMX modes: 2.3.4.7.14.26 DMX channels mode
℃
POWER INPUT
DMX INPUT
DMX OUTPUT
POWER OUTPUT
MBAR 120 User Manual/Manual de uso P 1
EN
