5.DMX Control Function
DMX Channels
3CH
.
3C
H
4C
H
6C
H
9CH VALUE FUNCTION
CH1 -
CH
1
CH
1
CH1 0-255 Dimming all
-
CH
1
CH
2
CH
2
CH2 0-255 Red
-
CH
2
CH
3
CH
3
CH3 0-255 Green
-
CH
3
CH
4
CH
4
CH4 0-255 Blue
CH2 - -
CH
5
CH5
0-5 No strobe
6-20 Not synchronous strobe(slow to fast)
21-60 Synchronous strobe(slow to fast)
61-100 Electronic Sinewave(slow to fast)
101-140 Random Strobe(slow to fast)
141-180 Opening pulse(slow to fast)
181-220 Closing pulse(slow to fast)
221-255 Electronic Squarewave(slow to fa
st)
-
- - -
CH6(CH
6 prior to
CH8)
0-10 No effect
11-15 CT01(Call custom color setting CT01)
16-20 CT02
21-25 CT03
26-30 CT04
31-35 CT05
36-40 CT06
41-45 CT07
46-50 CT08
51-55 CT09
