Marklin Digital 60985 - Wire Color Referencing; Cross Referencing the Colors for the Wires

28
gray Motor Connection 2 black Conductor Current Pickup, Left white Front Lights green Aux 1 physical output blue Common Wire for Lights yellow Rear Lights red Conductor Current Pickup, Right / Center orange Motor Connection 1 violet Aux 2 physical output brown Speaker brown Speaker
Description Wire Color
NEM Märklin
Motor Connection 2
gray blue
Conductor Current Pickup, Track, Left (DC)
Outer (AC)
black brown
Front Lights
white gray
Aux 1 (physical output)
green brown/red
Common Wire for Lights
blue orange
Rear Lights
yellow yellow
Conductor Current Pickup,
Track, Right (DC) Center (AC)
red red
Motor Connection 1
orange green
Speaker +
brown
white
Speaker –
brown
white
Aux 2 (physical output)
violet brown/green
IN1* Sound synchronization 1 (programmer) Blue / orange marking
IN2
* Sound synchronization 1 (programmer) Blue / yellow marking
GND* Decoder ground (Prgrammer) Blue / black marking
Aux 3
(physical output) Violet / yellow marking
Aux 4
(physical output) Violet / white marking
* Currently used only for the programmer.
Cross Referencing the Colors for the Wires
The colors for the wires correspond to the NEM 652
blue orange marking IN1 Sound synchronization 1 (programmer) blue yellow marking IN2 Sound synchronization 2 (programmer) violet yellow marking Aux 3 physical output violet white marking Aux 4 physical output blue black marking GND Decoder ground (Pr0grammer)
