13
which is connected to the running rails - see Figure
.
You can use any piece of C Track as the feeder track.
Plug the power cord (1) for the transformer into the wall
outlet for your household current.
6. Operation
6.1 Delta Addresses
The controler can identify a total of 4 addresses.
1 = 78
2 = 72
3 = 60
4 = 24
2 Locomotive Address
The locomotive addresses are set at the factory. The
addresses are given in the instructions for each locomo-
tive. These addresses are not binding; they can be
changed by following the instructions for the locomotive.
If you want to control a locomotive with the controller
in this set, an address must be set for the locomotive,
which can be selected with the controller. These ad-
dresses are:
Setting on the Address Selection
Switch
Locomotive
Address
1 78
2 72
3 60
4 24
6.3 Selecting a Locomotive
You look for the locomotive that you want to control on
the address selector switch (6).
78 selected 72 selected
