Split 418 UHD™ 39
APPENDIX: EDID SETTINGS
Tip: In standard situations, always use the automatic setting, which will
result in sound and image on all connected screens. With manual settings,
no image or sound may be displayed on one or more screens if the
appropriate setting is not supported.
#
EDID Selector
Description
1
0000
Copy EDID from HDMI OUT1
2
0001
1080p, Stereo Audio 2.0
3
0010
1080p, Dolby/DTS 5.1
4
0011
1080p, HD Audio 7.1
5
0100
1080i, Stereo Audio 2.0
6
0101
1080i, Dolby/DTS 5.1
7
0110
1080i, HD Audio 7.1
8
0111
3D,1080p, Stereo Audio 2.0
9
1000
3D, 1080p,DOLBY/DTS 5.1
10
1001
3D,1080p, HD AUDIO 7.1
11
1010
4K2K, Stereo Audio 2.0
12
1011
4K2K, DOLBY/DTS 5.1
13
1100
4K2K, HD AUDIO 7.1
14
1101
1080p, Stereo Audio 2.0
15
1110
1080p, Stereo Audio 2.0
16
1111
Automatic EDID
