Ref.Q'tyRef.Q'ty
No./ToolNo./Tool
195700Jaw Housing13195729Air Cylinder Cap1
295701Jaw1set3295730Screw Plug1
395702Jaw Pusher13395731Valve Pressure Spring1
495703Jaw Housing Coupler13495732Valve Plate2
595704Spring13595733Valve Spring1
695705Nut13695734Valve Tube1
795706Hydraulic Plunger13795735O-Ring 4.8x1.91
895707O-Ring 2.6x18.8x2413895736O-Ring 9.25x1.781
995708O-Ring Washer13995737Trigger Arm1
1095709Frame Cap14095738Spring 1
1195710Return Spring14195739Roll Pin1
129571124295740l/4" Air Inlet Fitting1set
139575014695741O-Ring 9.8x1.92
1495713Hydraulic Section14795742Hydraulic Section Nut1
1695714Head14895743Spanner1
17A95715l/8" Nosepiece(Accessories)149957551
17B957165/32" Nosepiece(Accessories)15095745Black Up O-Ring1
17C957173/16" Nosepiece(Accessories)15195746O-Ring1
2095718Air Piston Rod15295747Hanging Cilp1
2195719Front Piston Head Disc15495749Black Up O-Ring1
2295720Piston Head Packing Ring1
2395721Rear Piston Head Disc1
2495722Piston Head Spring Washer1
2595723Piston Head Lock Screw 1
2695724O-Ring 25.4x19.5x2.71
2795725Air Piston Rod Guide1
2895726Air Cylinder body1
2995727Air Piston Stop1
3095728O-Ring 4.8x2.41
File No.LR051/DD-04-11-020V1.0
Part No.DescriptionPart No.Description
Safety Cup
RK95752
SK
Instructions and Parts List - #79050
8, 9, 12(x2), 22, 26, 30, 33, 34(x2),
35, 37, 38,46(x2),50,51,54
Repair Kit Ref. No.--
3, 5, 11
Service Kit Ref. No.--
V-3 AIR / Hyhudraulic RIVETER TOOL
95753
O-Ring 8.8x1.9
14mm Wrench
