8/7/2003
5
Controls:
(4) Input level controls, METER control knob, ENCODE switch,
POWER ADJUST pot, TRANSMIT switch, and MONITOR jack.
SRPT-40A: FREQUENCY SELECT switches and EXECUTE switch
SRPT-30: F1/F2 switch
Power Requirements:
110-120 VAC or 220-240 VAC (manually switched internally on power
supply for proper input), 50/60 Hz
External DC operation on 12 - 15 volts or 15 - 30 volts.
Approximate PA Current
Rating (at maximum power
output):
SRPT-40A: 8.5 to 10.5 Amps
SRPT-30: 6.5 to 7.5 Amps
(The data above varies across frequency band and from model to model)
Accessory Connector:
15-pin D connector for DC power, remote control, encode, line level
input.
Weight:
Net: 8.25 Lbs (3.74 Kg).
Packed: 16.75 Lbs (7.60 Kg).
Dimensions:
11.5in (29.21cm) W x 3.5in (8.89cm) H x 14.3in (36.83cm) D.
Packed: 19in (48.26cm) W x 22in (55.88cm) H x 9in (22.86cm) D.
* - There does exist a few non-standard frequencies that will not automatically tune to within .00015% of
requested frequency. For those frequencies, the operator must change to the nearest standard frequency and
then manually tune the reference oscillator to desired frequency. Consult factory for frequencies not perfectly
divisible by 5 KHz or 6.25 KHz. We will be able to tell you how close the output will come to desired frequency.
