Maruyama MSD41 - Page 15

Inlet Valve Seat
Piston Packing
Spacer
Piston Retainer
Spring Washer
Nut
Install the inlet valve
seat and spacer onto
the piston rod.
Lubricate the piston
packing with light oil
and slide it over the
spacer. The square
cut edge goes toward
manifold B.
Now install the Piston
Retainer, Spring
Washer, and Nut.
Finally tighten the
nuts down.
