ITEM NO PART NO DESCRIPTION QTY
40 3002001 EXCITER BOX 1
41 3002002 BOX COVER 1
42 0700008-25 BOLT M8 x 25-GB70 9
43 0930008 SPRING WASHER8-GB93 30
44 0119008 PIN BOLT8-GB119 2
45 0283006 BEARING32206-GB283 2
46 0987752
OIL SEAL ∮52 x ∮28 x 7-GB9877.1
1
47 3002003 BEARING COVER 1
48 0700008-20 BOLT M8 x 20-GB70 12
49 3002004 PULLEY 1
50 3002005 WASHER 1
51 0109608 KEY C20 x 8-GB1096 1
52 0578308 BOLT M8 x 20-GB5783 1
53 3002006 BEARING COVER 2
54 0276006 BEARING60206-GB276 2
55 3002007 PINCH CLAMP 1
56 3002008 BOLT M20 1
57 3002009 BOLT 1
58 0854010 WASHER10-GB854 10
59 0617010 NUT M10-GB6170 1
60 0910003
SPLIT PIN ∮2.5 x 20-GB91
1
61 3002010 SPINDLE 1
62 3002011 UNBALANCE WEIGHT 1
63 0894040 RETAINING RING40-GB894 2
64 3002012 CLUTCH ASSY 1
65 3002013 DIRECTION PIN 1
66 0730008 BOLT M8 x 25 1
( TO BE CONTINUED)
MSH160 & MSH160E PARTS LIST 3
11
To Next Page
