MASCOT 2240 - Page 15

15
Input voltage
Charge LED
indicator
6V 12V 24V 36V 48V
2541(P) 2542(P)
100-240Vac
50-60Hz
max. 0.9A
Orange CC ch.: Orange CV ch.: Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
2.7A < 7.35V 7.35V > 1.2A 7.35V < 1.2A
6.85V < 250mA
11Ah – 12.5Ah
2.2A < 14.7V
14.7V > 1A 14.7V < 1A
13.7V < 250mA
11Ah – 12.5Ah
1.2A < 29.4V 29.4V > 0.5A 29.4V < 0.5A
27.4V < 250mA
6Ah – 12.5Ah
0.8A < 44.1V 44.1V > 0.4A 44.1V < 0.4A
41.1V < 250mA
4Ah – 12.5Ah
0.6A < 58.8V
58.8V > 0.25A 58.8V < 0.25A
54.8V < 100mA
3Ah – 5Ah
2544 10-30Vdc
Orange CC ch.: Orange CV ch.: Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
2.7A < 7.35V
7.35V > 1.15A 7.35V < 1.15A
6.85V < 250mA
12Ah – 12.5Ah
2A < 14.7V
14.7V > 0.85A 14.7V < 0.85A
13.7V < 250mA
10Ah – 12.5Ah
1.2A < 29.4V 29.4V > 0.5A 29.4V < 0.5A
27.4V < 250mA
6Ah – 12.5Ah
0.8A < 44.1V 44.1V > 0.4A 44.1V < 0.4A
41.1V < 250mA
4Ah – 12.5Ah
0.6A < 58.8V
58.8V > 0.25A 58.8V < 0.25A
54.8V < 100mA
3Ah – 5Ah
Input voltage
Charge LED
indicator
6V 12V 24V 36V 48V
2240(P) 2241(P)
100-240Vac
50-60Hz
max. 0.35A
Orange CC ch.: Orange CV ch.: Green Float ch.: Rec. batt. capacity:
1.3A <7.35V
7.35V >250mA 6.85V <250mA
6.5Ah – 12.5Ah
1A <14.7V
14.7V >250mA 13.7V <250mA
5Ah – 12.5Ah
0.56A <29.4V
29.4V >250mA 27.4V <250mA
2.8Ah – 12.5Ah
0.35A <44.1V
44.1V >150mA 41.1V <150mA
1.8Ah – 7.5Ah
0.27A <58.8V
58.8V >100mA 54.8V <100mA
1.4Ah – 5Ah
2740
100-240Vac
50-60Hz
Orange CC ch.: Orange CV ch.: Green Float ch.: Rec. batt. capacity:
1.0A <7.35V
7.35V >200mA 6.85V <200mA
5Ah – 10Ah
0.7A <14.7V
14.7V >200mA 13.7V <200mA
3.5Ah – 10Ah
0.35A <29.4V
29.4V >100mA 27.4V <100mA
1.8Ah – 5Ah
0.24A <44.1V
44.1V >100mA 41.1V <100mA
1.2Ah – 5Ah
0.18A <58.8V
58.8V >50mA 54.8V <50mA
0.9Ah – 2.5Ah
Charge diagram A
Technical data (If not appearing in table see marking on the product)
Charge diagram B
(P) = 2MOPP version. (All standard versions are also available as open frame units).
