15. MAINTENANCE
WARNING
Improper adjustment of the handlebars or incorrect torquing of
the adjuster block tightening bolts can cause limited steering or
loosening of the handlebars, resulting in loss of control and
possible serious personal injury or death.
Handlebar Adjustment
Your ATV has handlebars
which can be adjusted for
your personal fit.
1. Remove the handlebar cover.
2. Loosen the four bolts.
3. Adjust handlebar to desired
height. Be sure handlebars do
not hit gas tank or any other part
of machine when turned fully to left or right.
4. Torque handlebar adjuster block to 10-12 ft.Ibs(14-16Nm).
NOTE: Tighten bolts so there is an equal gap at the front and rear
of the handlebar block. Improper gap will result in improper fit of
upper pod.
