Massive Audio M6 - Massive Audio M6 M Speaker Specifications; Specifications Overview; M6 M Thiele & Small Parameters

Specifications M6M
Nominal Basket Diameter 6.5",168mm
Nominal Impedance 4 ohms
RMS Watts 140 W
Music Program 400 W
Resonance 270 Hz
Usable Frequency Range 270Hz-10KHz
Sensitivity 99 dB
Magnet Weight 16 oz
Gap Height 0.24”
，
6mm
Voice Coil Diameter 1.5” 38.5mm
Resonant Frequency (fs) 167.6Hz
DC Resistance (Re) 2.6
Mechanical Q (Qms) 5.58
Electromagnetic Q (Qes) 6.42
Total Q (Qts) 0.58
Compliance Equivalent Volume (Vas) 2.22 L
Mechanical Compliance of Suspension (Cms) 79.72 uM/N
BL Product (BL) 6.95 TM
Diaphragm Mass Inc. Airload (MMs) 11.3 g
Surface Area of Cone (Sd) 0.014 Sqm
Overall Diameter 6.5",168mm
Baffle Hole Diameter 5.57",144mm
Front Sealing Gasket Fitted as standard
Rear Sealing Gasket Fitted as standard
Mounting Holes Diameter 0.22",5.5mm
Mounting Holes B.C.D. 6.1",155mm
Depth 3.19",81mm
Net Weight 3.52lbs
，
1.6KG
Shipping Weight 4.62lbs,2.1Kg
Coil Construction Copper voice coil
Coil Former Kapton former
Magnet Composition
Neodymium and strontium hybrid magnet
Core Details Vented and extended core
Basket Materials Cast aluminum basket
Cone Composition Paper Cone
Cone Edge Composition Flat foam surround
Dust Cap Composition Neodymium Phase plug
Materials of Construction
Thiele & Small Parameters
Mounting Information
MASSIVE AUDIO PRO AUDIO SPECIFICATIONS
