Massive Audio M6 - Massive Audio T 44 Driver Details; T 44 Thiele & Small Parameters

Specification T 44
Throat Size 1.3"X1.3" 33X33mm
Nominal Impedance 8 ohms
Power Rating RMS 60 W
Usable Frequency Range 4K-20KHz
Sensitivity 105 dB
Magnet Weight 37 Oz
Voice Coil Diameter 1.75", 44.4mm
DC Resistance (Re) 7.2
Overall Diameter 4.8"X4.8" 122X122mm
Mounting Holes Diameter N/A
Mounting Holes B.C.D. 4.4",111.76mm
Depth 2.87",73mm
Net Weight 2.95lbs,1.34Kg
Shipping Weight 3.74lbs,1.7Kg
Diaphragm Material Aluminum
Magnet Composition Titanium magnet
Thiele & Small Parameters
Mounting Info
Materials of Construction
MASSIVE AUDIO PRO AUDIO SPECIFICATIONS
