Massive Audio M6 - Massive Audio M8 Speaker Specifications; M8 Thiele & Small Parameters

Specifications M8
Nominal Basket Diameter 8.2" 210mm
Nominal Impedance 8 ohm
RMS Watts 150 W
Music Program 280 W
Resonance 100Hz
Usable Frequency Range 100Hz-7KHz
Sensitivity 96dB
Magnet Weight 40 oz
Gap Height 0.24"
，
6mm
Voice Coil Diameter 1.5",38.5mm
Resonant Frequency (fs) 100Hz
DC Resistance (Re)
5.2
Mechanical Q (Qms) 1.482
Electromagnetic Q (Qes) 0.627
Total Q (Qts) 0.441
Compliance Equivalent Volume (Vas) 11.2 L
Mechanical Compliance of Suspension (Cms) 187.53 uM/N
BL Product (BL) 8.17
Diaphragm Mass Inc. Airload (MMs) 12.2
Surface Area of Cone (Sd) 0.02 sqm
Overall Diameter 8.2" 210mm
Baffle Hole Diameter 7.24",184mm
Front Sealing Gasket Fitted as standard
Rear Sealing Gasket Fitted as standard
Mounting Holes Diameter 0.20"X0.33",5.2X8.6mm
Mounting Holes B.C.D. 7.8",198mm
Depth 3.62",92mm
Net Weight 5.7lbs,2.58Kg
Shipping Weight
7lbs,3.2Kg
Coil Construction Copper voice coil
Coil Former Kapton former
Magnet Composition Ferrite magnet
Core Details Vented and extended core
Basket Materials Pressed steel basket
Cone Composition Paper Cone
Cone Edge Composition Cloth cone edge
Dust Cap Composition Phase plug
Materials of Construction
Thiele & Small Parameters
Mounting Information
MASSIVE AUDIO PRO AUDIO SPECIFICATIONS
