Massive Audio M6 - Massive Audio PAT 1 Driver Details; PAT 1 Thiele & Small Parameters

Specification PAT 1
Throat Size 1"(25mm)
Nominal Impedance 8 ohm
Power Rating RMS 25 W
Usable Frequency Range 1K-18KHz
Sensitivity 102 dB/w/m
Magnet Weight 37 Oz
Voice Coil Diameter 25.4mm
DC Resistance (Re) 7 ohm
Overall Diameter 2.2"/55.88mm
Mounting Type Screw on 1 3/8”
Depth 2.3"/58.42mm
Net Weight .25lbs/.11kg
Shipping Weight 15 kg
Diaphragm Material Phenolic
Magnet Composition Neodymium
Thiele & Small Parameters
Mounting Info
Materials of Construction
MASSIVE AUDIO PRO AUDIO SPECIFICATIONS
