Massive Audio M6 - Massive Audio PAT 34 Driver Details; PAT 34 Thiele & Small Parameters

Specification PAT 34
Throat Size 1"(25mm)
Nominal Impedance 8 ohm
Power Rating RMS 50 W
Usable Frequency Range 1.2K-20KHz
Sensitivity 108 dB/w/m
Magnet Weight 37 Oz
Voice Coil Diameter 34.4mm
DC Resistance (Re) 6.4 ohm
Overall Diameter 3.8"/96.52mm
Mounting Type Bolt-on 4-Φ76-M6
Depth 2.5"/63.5mm
Net Weight 2.90 Lbs/1.315 kg
Shipping Weight 17 kg
Diaphragm Material Titanium
Magnet Composition Ferrite
Thiele & Small Parameters
Mounting Info
Materials of Construction
MASSIVE AUDIO PRO AUDIO SPECIFICATIONS
