Massive Audio M6 - Massive Audio PAT 50 A Driver Details; PAT 50 A Thiele & Small Parameters

Specification PAT 50A
Throat Size 1"(25mm)
Nominal Impedance 8 ohm
Power Rating RMS 60 W
Usable Frequency Range 1.0K-20KHz
Sensitivity 109 dB/w/m
Magnet Weight 37 Oz
Voice Coil Diameter 51.6mm
DC Resistance (Re) 7.0 ohm
Overall Diameter 5.2"/132.08mm
Mounting Type Bolt-on 4-Φ76-M6
Depth 3.9"/99.06mm
Net Weight 5.80Lbs/ 2.63 kgs
Shipping Weight 17 kgs
Diaphragm Material Titanium
Magnet Composition Ferrite
Thiele & Small Parameters
Mounting Info
Materials of Construction
MASSIVE AUDIO PRO AUDIO SPECIFICATIONS
