Step 7
Pass the shoulder straps and pads
over the child‘s shoulders on the
both sides, then insert the buckle
6, until you hear an audible „click”
sound.
Step 8
Grasp the 5-point harness strap 10, pull it forward slowly until the
tightness is comfortable for your child (make sure it is not crossed or
twisted).
Attention:
The shoulder strap has reached a suitable level of tightness when
there is space for two adult fingers between the shoulder pad
and the child.
Rotating the seat
Step 1
Pull the rotation adjust handle 12, rotate
the seat to rear or forward facing, until
you hear an audible „click”. Shake the
seat to make sure it is locked correctly.
10
6
click
12
click
