103
4.2
100-150cm forward facing
Method 1: ISOFIX + vehicle belt
Method 2: Vehicle belt
Storing the support leg
Step 1
Press the support leg adjust button 19
to adjust the leg to the shortest position
(as shown in the figure).
Step 2
Fold the supporting leg less than
45°and pull the supporting leg A back
to the base. When you hear the „click”
sound, it indicates that it is correct.
Step 3
Fold the supporting leg until it is fully
stored in the base.
Hiding the 5-point harness
Step 1
Before hiding the 5-point harness,
please remove the cushion 9 (the
cushion should be removed when
the seat is used for a child who is
100-150cm tall)
i-Size
click
A
click
9
8
4
M.ROX manual car seat 06.03.2023.indd 104M.ROX manual car seat 06.03.2023.indd 104 13.03.2023 14:41:1113.03.2023 14:41:11
