MAST M.Rox - Page 109

DEUTSCH
108
5.6
Adjusting the shoulder straps
Loosen the shoulder straps
Press the harness adjust button
7. At the same time, pull the two
shoulder straps out to a convenient
length. Do not only pull on one of
the shoulder straps
Tighten the shoulder straps
Grasp the 5-point harness strap 10,
pull it forward slowly until the
tightness is comfortable for your
child
WARNING
- Please loosen the shoulder straps, then tighten them if the 5-point
harness strap is locked
- Check and tighten the ISOFIX and 5-point
harness. Make sure that the seat and the child
are firmly in place.
- The 5-point harness must not be twisted or
entangled.
- Use the ISOFIX guide 21 for easy installation
of the ISOFIX
10
7
21
21
