2. Car seat components
Front View
1 Headrest
2 Head pillow
3 Shoulder strap guide hook
4 Shoulder pad
5 Shoulder strap
6 5-point buckle
7 Harness adjust button
8 Buckle pad
9 Cushion
10 5-point harness strap
11 Recline adjust handle
12 Rotation adjust handle
13 Waist cushion
Back View
14 Head adjust handle
15 Lap belt guide groove
16 ISOFIX
17 ISOFIX secondary lock button
18 ISOFIX release button
19 Support leg adjust button
20 Support leg
21 ISOFIX guide sleeve
22 Fabric cover
23 Lap belt hook
24 Reversible cover plate
14
16
i-Size
19
17
18
21
22
15
23
24
20
