• Adjust each speaker to the appropriate tap setting before installing the grille (only
in CS6MC/T)
• Insert the grilles to the speakers:
o Press the grille into place until the front of the grille is flush with the rim of
the baffle
o Check that the grille is securely seated
o To remove the grille, insert two bent paper clips into the holes in the grille
and carefully pull it down. Repeat this around the perimeter of the grille
until it is completely removed.
4. TECHNICAL FEATURES
CS6/T CS6FR CS6MC/T
Power handling
R.M.S 10W (direct) 30W (direct) 30W (direct)
Program 20W (direct)
100V Line (5W/10W)
60W (direct)
100V Line
(2W/5W/10W/20W)
60W (direct)
100V Line
(3W/6W/12W/25W/50W)
Components
1x6.5” dual cone
woofer
1x6.5” coaxial woofer 1x6.5” coaxial woofer
Frequency
response
(-10dB)
78 Hz – 19kHz 60 Hz – 20kHz 75 Hz – 20kHz
Sensitivity
92 dB 90 dB 89 dB
Impedance
16 Ω 16 Ω 16 Ω
100V Line (2kΩ/1kΩ) 100V Line
(5kΩ/2kΩ/1kΩ/500Ω)
o
(2kΩ/1kΩ/500Ω
/250 Ω)
100V Line
(3k3Ω/1k6Ω/800Ω/400Ω
/200Ω)
Connections
Terminal strip Push terminals Push terminals
Dimensions
(ØExt/ØInt)
228mm / 194mm 228mm / 194mm 251mm / 221mm
Depth (inner)
81mm 97mm 104mm
Weight
0.9 Kg 1.5 Kg 2.4 Kg
5. WARRANTY
All MASTER AUDIO products manufactured by Amate Electroacústica, s.l. have been
conceived under strict manufacturing rules and have passed rigorous quality controls to
guarantee an excellent and long product performance even under the hardest conditions.
Amate Electroacústica, s.l.
extends its Warranty Certificates for each group of products
according to their technological characteristics in order to cover manufacturing defects of
the product or any of its components, including necessary workmanship for its replacement.
The
validity period
depends of each group of products, and it is determined in the
following manner:
