Xcellence Line Array Series 208.Ver 1.2 Sep 12
31
Fig.22b. X215W total back energy rejection. Yellow curve without central cardioid
subwoofer; orange curve adding central cardioid subwoofer.
Fig.22c. X218W total back energy rejection. Yellow curve without central cardioid
subwoofer; green curve adding central cardioid subwoofer.
IMPORTANT: If the user wants to adjust its own cardioid preset there is a
specific manual to do it. Please, contact the sales department of Master Audio
for more information.
